Onkyo P-3000R User Manual

31
En
Playing Music Files on the PC
This section explains how to play music files on a PC
through the preamplifier.
To playback the audio data stored on your PC by using the
preamplifier via USB port connection, you must install the
driver on your PC from the Onkyo website.
For the installation procedure, see the Onkyo Web site.
Note
• If you play incompatible file formats, then sound may not be
output depending on the player software on the PC.
• If the sampling rate is greater than 96 kHz, no sound will come
out of digital outputs.
• The USB selector on the display flashes if you unplug the USB
cable.
• If the USB connector of your PC does not support the high-speed
2.0 standard, then audio is not output.
Connecting the PC
PC
USB
Installing a USB Driver Playing Music Files on the PC
1
Press USB to switch the input to the USB selector.
You can also use preamplifier’s Multi jog dial.
2
Play music files on the PC.
USB

Onkyo P-3000R Specifications

General

Output level	0.001 mV
Amplifier class	-
Frequency range	5 - 100000 Hz
Output impedance	330 Ω
Input sensitivity	200 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.005 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Digital audio optical in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	29 W
Package weight	12500 g

Weight and Dimensions

Depth	333.1 mm
Width	435 mm
Height	99 mm
Weight	11000 g
