18
Falcon User Manual - Remittance Processing - OPEX Corporation
Main Controls and System components
The list below describes many of the controls and components of the Falcon
system. Refer to Figure 2 on page 20.
Main power switch The main power switch is located on the left cover, as
shown in Figure 2. This is the main “on/off” switch for the Falcon system.
UPS (Uninterrupted Power Supply) The APC UPS supplies battery power
to the PC and monitor to allow a controlled shutdown of the Windows operating
system. The scanner should be plugged into the AC wall outlet and not the
UPS.
CertainScan PC The 32-bit or 64-bit PC with Windows 7 operating system
houses OPEX’s feature-rich CertainScan 3.1 host software.
Touchscreen monitor Use the monitor to log in and out of the Falcon
system. The monitor’s touchscreen controls should be used to operate the
system and run jobs.
Keyboard/mouse Typically, the keyboard and mouse are only used for
setting up jobs and for use with other software. Use the touchscreen monitor
for running jobs and operating the machine.
MFD Override button The MFD override button
allows you to disable the ultrasonic multifeed
detector when you are scanning thicker pieces,
such as items with sticky notes attached.
IDAssist indicator The blue IDAssist indicator
LED will light up when running a job that includes
IDAssist. Also, when the operator triggers IDAssist
the LED will go out briefly, indicating to the
operator that IDAssist has been activated. For
more on using IDAssist, see “IDAssist” on page 67.
