Installation of the converter
- 18 -
optek-Manual--1004-1022-02--156-US-2017-12-11
www.optek.com
7.3 Requirements for mounting with mounting angle
• The wall, the converter is to be installed to, is of sufficient bearing
capacity.
• Weight and dimensioning details of the converter are given in the
technical data.
• An external release device on the control cabinet is located close to the
converter. With this device the converter can be switched voltage-free.
Tool • Screw driver
• Installation kit W19
consisting of:
1 x mounting angle W19
2 x nut plate M2.5 28HP s=4.5 (H-profile)
4 x screw M2.5 x 8 DIN 7985 A2
7.4 Mounting with mounting assembly
1. Prepare the wall for fixing the mounting assembly so that the assembly may
be fixed to the wall with the small side.
2. Mount the mounting assembly with the large side in a horizontal position.
3. Fix the converter at the right side to the mounting assembly. Fasten the four
screws on mounting assembly and converter.
