11 Spare parts and accessories
11.1 Accessories converter
Tab. 8 Accessories - housings and installation kits
Accessories Description Part number
Installation kit X56
4 x collar screw M2.5 x 11
4 x plastic sleeve M2.5
2 x fuse T 0.630 A 115 V AC
2 x fuse T 0.315 A 230 V AC
2 x fuse T 1.25 A 24 V AC/DC
1200-3317-0007-00
Installation kit W19
1 x mounting angle W19
2 x nue plate M2.5 28HP s=4.5 (H-profile)
4 x screw M2.5 x 8 DIN7985 A2
1200-3317-0001-00
B19-21 (IP66)
1 x X56
Wall mount housing B19-21
- Material: plastic (ABS)
- Protection: IP66
for 1 Converter X56
(Installation kit B19
PN: 1200-3390-0001-00 included)
1200-3317-0002-00
B19-42 (IP66)
1 x X56
Wall mount housing B19-42
- Material: plastic (ABS)
- Protection: IP66
for 1 Converter X56
Blind plate for second slot
(Installation kit B19
PN: 1200-3390-0001-00 included)
1200-3317-0003-00
B19-42 (IP66)
2 x X56
Wall mount housing B19-42
- Material: plastic (ABS)
- Protection: IP66
for 1 Converter C4000, HazeControl
or for 2 Converter X56
(Installation kit B19
PN: 1200-3390-0001-00 included)
1200-3321-0002-00
S19-42 (IP65)
1 x X56
Wall mount housing S19-42
- Material: stainless steel 1.4301 / SS304
- Protection: IP65
for 1 Converter X56
Blind plate for second slot
(Installation kit S19
PN: 1200-3390-0003-00 included)
1200-3317-0005-00
S19-42 (IP65)
2 x X56
Wall mount housing S19-42
- Material: stainless steel 1.4301 / SS304
- Protection: IP65
for 1 Converter C4000, HazeControl
or for 2 Converter X56
(Installation kit S19
PN: 1200-3390-0003-00 included)
1200-3321-0003-00
Blind plate 3 HE-21TE
Blind plate 3 U-21HP
consisting of:
1 x blind plate 3U-21HP
4 x collar screw M2.5 x 11
4 x plastic sleeve M2.5
1200-3390-0004-00
