Wiring
- 22 -
optek-Manual--1004-1022-02--156-US-2017-12-11
www.optek.com
Tool • Screw driver
To be able to allocate the end splices unequivocally to the terminals of the
converter, each end splice is marked with the number of the correct terminal:
Detector cable to sensor
1 = white (A1) 2 = brown (A2) 5 = black (A5)
Lamp cable to sensor
6 = white or blue (6) 7 = brown (7)
Caution!
Lamp voltage must be adjusted to the cable length in order to compensate volta-
ge loss in the cable. Too low lamp voltage can lead to wrong measuring
results. Too high lamp voltage reduces the life of the lamp module considerably.
