Pulsar
2
Service Manual
OPTIKON 2000
Cod. 111004SEN Rev.C
7-4
PRIMING ERRORS
The errors described below are only delivered during the priming procedure.
They are often due to misuse, not to equipment malfunctions.
• Err 11: Vac offset
Some vacuum is present at start of priming procedure although aspiration
pump has not been activated yet. This could be due to the following
reasons:
a) Priming has been restarted after an Err 13. Open the irrigation clamp
and restart
the priming procedure.
b) Cassette ha been left set on the console for several hours. Replace
cassette.
c) Vacuum sensor needs offset re-calibration.
• Err 12: Major leakage
The peristaltic pump cannot built-up 100mmHg: There is a major leakage
in the I/A system. This could be due to one of the following:
a) The I/A cassette is not properly latched in position.
b) Test chamber is not installed on the sleeve.
c) I/A lines are not connected to the handpiece.
d) The cassette is defective.
e) Any of the valves (Irrigation, Reflux/venting, Venturi) is defective or
improperly
calibrated.
f) The vacuum sensor in the equipment is malfunctioning.
• Err 13: No irrigation
To release the vacuum, the reflux/venting valve is open. If the vacuum
does not drop to zero, very likely no irrigation is flowing, irrigation clamp
on the line from the drip chamber is closed or the line is bent (a
malfunction of the reflux/venting valve causes an Err 12).
• Err 14: Aspiration occluded
After venting, the line are filled with BSS by the action of the peristaltic
pump. During this phase the vacuum should remain below 200mmHg. If it
builts-up to higher levels, the aspiration line is completely or partially
occluded. This could be due to:
a) The handpiece and/or tip have not been properly cleaned before
sterilization.
b) The aspiration line is bent or occluded.
c) The tip used is a high-vacuum low-flow non OPTIKON® tip.
d) The equipment is not connected to the electric pole in the cart and the
bottle is
too low.
