EX540/EX542/EX612/EX615/EX762/EX540I/EX542I/ES523ST/EW533ST
Condential IX
Item P/N Description Parts Supply
1 70.8EF26G001 MAIN BOARD IO BOARD ASSY EX612
2 61.8EG02G011 MAIN BOARD SHIELDING EX612
70.8EJ04GR01
ASSY IO COVER MODULE FOR EX542
(SERVICE)
V
70.8FK02GR01
ASSY IO COVER MODULE FOR EX612
(SERVICE)
V
70.8EF44GR01
ASSY IO COVER MODULE FOR EX615
(SERVICE)
V
3 51.8EG10G011 IO COVER EX612
4 41.86R01G001
ADUIO I/O PORT EMI GASKET W13*H1*L13mm
diameter 6.5mm
5 85.005AGG408 SCREW HEX I/O #4-40 H4*L8 NI NYLOK
6 85.1A123G050 SCREW PAN MECH M3*5 Ni
7 51.8EF04G001 MAIN BOARD MYLAR EX542
8 52.8EF02G001 MAIN BOARD SPONGE EX615
9 52.8EF04G001 MAIN BOARD SPONGE 20mm EX615
10 41.85Y04G002
EMI GASKET (S-VIDEO & S-VIDEO)
W18*H0.35*L17 mm
To Next Page
