Optoma EX615 - Chapter 2 Disassembly Process

EX540/EX542/EX612/EX615/EX762/EX540I/EX542I/ES523ST/EW533ST
Condential
III
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-3
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover Module 2-2
Disassemble Lamp Module 2-2
Disassemble Focus Ring 2-3
Disassemble Top Cover Module 2-3
Disassemble Keypad Board Module and Zoom Ring 2-4
Disassemble Top Shielding 2-5
Disassemble Main Board Module 2-5
Disassemble Daughter Board and Lan Module Board 2-8
Disassemble Engine Module 2-9
Disassemble Color Wheel Module 2-9
Disassemble DMD Chip and DMD Board 2-10
Disassemble Rod Module 2-10
Disassemble System Fan Module and Thermal Switch 2-11
Disassemble Speakers 2-12
Disassemble Blower 2-13
Disassemble Front IR Module 2-14
Disassemble LVPS Module and Interlock Switch 2-14
Disassemble Lamp Driver Module 2-15
Disassemble Security Bar Cap 2-15
Disassemble Bottom Shielding 2-16
