Optoma EX615 - 2-2 Lamp Cover Module Disassembly; 2-3 Lamp Module Disassembly

EX540/EX542/EX612/EX615/EX762/EX540I/EX542I/ES523ST/EW533ST
Condential 2-2
2-3 Disassemble Lamp
Module
1. Loosen 2 screws (as red circle) on the
Lamp Module.
2. Take off the Lamp Module.
2-2 Disassemble Lamp
Cover Module
1. Loosen 2 screws (as red circle) on the
Lamp Cover.
2. Disassemble the Lamp Cover Module.
