EX540/EX542/EX612/EX615/EX762/EX540I/EX542I/ES523ST/EW533ST
Condential
4-1
Chapter 4
Function Test & Alignment Procedure
4-1 Test Equipment Needed
- IBM PC with XGA resolution
- DVD player with Multi-system, equipped “Component”, “S-Video”,“Composite” and
"HDMI".
- HDTV Source (720P,1080P,1080i)
- Minolta CL-100
- Quantum Data 802B or CHROMA2327 (Color Video Signal & Pattern Generator)
4-2 Service Mode
- EX542/EX612/EX615/EX540/EX762/EX540I/EX542I/ES523ST/EW533ST have two kinds of
Service Mode, use different ways to get into each Service Mode:
1. Turn on the projector
2. (1) Press "Power", "Left", "Left" and "Menu" buttons sequentially to get into Service Mode 1.
(2) Press "Power", "Up", "Down" and "Menu" button sequentially to get into Service Mode 2.
(3) Select "Exit" to leave the Service Mode after conrming the conguration.
4-3 OSD Reset
- After nal QC step, we have to erase all saved change again and restore the OSD default setting.
The following actions will allow you to erase all end-users' settings and restore the default setting:
1. Please get into OSD menu.
2. Execute "Reset" function.
