Optoma EX615 - 4-5 Defect Specification Tables

Condential
4-3
EX540/EX542/EX612/EX615/EX762/EX540I/EX542I/ES523ST/EW533ST
4-5 Defect specication table
For EX762/EX542I/ES523ST
Order Symptom Pattern Criteria
1 Bright pixel ( dots) Gray 10 pattern A+B=0
2 Dark pixel(dots) White pattern A+B≤4
3 Unstable pixel (dots) Any pattern A+B=0
4 Adjacent dark pixel (dots) Any pattern A+B=0
5 Dark blemish (Dirty) Blue 60 pattern
A+B≤2
(diameter <1/2 inch)
6 Bright blemish (Dirty) Gray 10 pattern
A+B≤2
(diameter <1/2 inch)
7 Bright dots on frame Gray 10 pattern ≤1
For EX542/EX612/EX615/EX540/EX540I
Order Symptom Pattern Criteria
1 Bright pixel ( dots) Any pattern A+B=0
2 Dark pixel(dots) Any pattern A+B≤4
3 Unstable pixel (dots) Any pattern A+B=0
4 Adjacent dark pixel (dots) Any pattern A+B=0
5 Dark blemish (Dirty) Blue 60 pattern
A+B≤4
(diameter <1 inch)
6 Bright blemish (Dirty) Gray 10 pattern
A+B≤4
(diameter <1 inch)
7 Bright dots on frame Any pattern ≤1
