EX540/EX542/EX612/EX615/EX762/EX540I/EX542I/ES523ST/EW533ST
Condential
II
Item P/N Description Parts Supply
1 70.8EF11G001 EX612 ASSY BOTTOM HOUSING MODULE
2 70.8EF01G001 ASSY OPTICAL ENGINE MODULE EX612
3 70.8EF08G001 MAIN BOARD ASSEMBLY EX612
4 70.8EF06G001
TOP COVER AND ZOOM RINGASSYEMBLY
EX612
5 51.8EF02G001 FOCUS RING EX612 (FOR YM09)
70.8EF45GR01 ASSY LAMP COVER BLACK EX615 (SERVICE) V
6 51.8EG03G011 LAMP COVER BLACK EX615
7 61.00018G002 LOCK SCREW PAN MECH M3*8.5-3.5 BLACK
8 SP.8EF01GC01 LAMP MODULE FOR PROJECTOR EX542 V
8 SP.8EG01GC01 LAMP MODULE FOR PROJECTOR EX615/EX612 V
9 41.83M06G001 EMI TAPE W30*L70mm
10 85.1A123G050 SCREW PAN MECH M3*5 Ni
11 85.00823G080 HEX SCREW M3*H8*L5.3,BRASS
12 61.8EG03G001 TOP SHIELDING HD20
13 85.0A122G030 SCREW DOUBLE FLAT MECH M2*3Ni
14 85.1A323G080 SCREW PAN MECH M3*8 BLACK “GREEN”
15 85.1A526G060 SCREW PAN MECH M2.6*6 Ni NYLOK
16 70.8EG17G001 ASSY 8525 FAN SHIELDING MODULE HD20
17 85.1A123G060 SCREW PAN MECH M3*6 NI
