EX765/EW766/EX765W/EW766W
Condential
6-2
6-2 Equipment Needed
Software
Note:There are two EDID,one is for HDMI, the other is for VGA1, VGA2 and DVI.
When burning in EDID, there is no need to power on the projector.
- EDID .exe
- EDID le(*.ini)
Hardware
- EX765 unit
- HDMI(M) to DVI(F) Adapter P/N:42.82B13G001
- DVI to DVI cable P/N:42.83N06G001
- RS-232 9 pin cable ( Male to Female) P/N:42.83C07G001
- EDID Fixture (JP3 must be closed) P/N:80.00001.001
- PC
- VGA to VGA cableX2 P/N:42.87305G102
- Power adapter for xture P/N:47.57803G001
- Power cordX2 P/N:42.50115G001
Note: The EDID upgrade procedure for EX765/EW766/EX765W/EW766W are the same.Here, we
take EX765 as an example.
