User Controls
DISPLAY
Format
Use this function to choose your desired aspect ratio.

4:3: This format is for 4×3 input sources.

16:9: This format is for 16×9 input sources, like HDTV and DVD
enhanced for Wide screen TV.

16:10: This format is for 16x10 input sources like high resolution
computer graphical applications and for large workspace for
report viewing.

LBX: This format is for non-16x9, letterbox source and for users
who use external 16x9 lens to display 2.35:1 aspect ratio using
full resolution.

Native: This format displays the original image without any
scaling.

AUTO: Automatically selects the appropriate display format.
16:10 Screen 480i/p 576i/p 1080i/p 720p PC
4:3 1600 x 1200 center
16:9 1920 x 1080 center
16:10 1920 x 1200 center
LBX
1920 x 1440 center, then get the central 1920 x 1200
image to display
Native
No resize image, 1:1 mapping and centered. This format
shows original image without scaling.
