Oracle Database Appliance X6-2-HA Owner's Guide

Supported Components and Capabilities
Chapter2 • Overview of Oracle Database Appliance 13
Component Oracle Database Appliance
X6-2S
Oracle Database Appliance
X6-2M
Oracle Database Appliance
X6-2L
Oracle Database Appliance
X6-2-HA
“Optional Component
Installation” on page 58.
“Optional Component
Installation” on page 58.
slots 0-1 reserved for
operating system storage
and system booting
■ Ten 2.5-inch 1.6 TB
SAS SSDs (in 3.5-inch
mounting brackets) in
slots 0-9
■ Base storage shelf
configuration: Filler
panels in slots 10-19
Full storage shelf
or standard storage
expansion shelf
configuration: Ten 2.5-
inch 1.6 TB SAS SSDs
(in 3.5-inch mounting
brackets) in slots 10-19
Note - Optional 1.6
TB SAS SSDs can be
added to these slots. See
“Optional Component
Installation” on page 58.
■ Four 2.5-inch 200 GB
high endurance SAS
SSDs (in 3.5-inch
mounting brackets) in
slots 20-23
USB 2.0
ports
Six total (two front, two rear
and two internal) per server
node.
Six total (two front, two rear
and two internal) per server
node.
Six total (two front, two rear
and two internal) per server
node.
Six total (two front, two rear
and two internal) per server
node.
PCI Express
(PCIe) I/O
slots
Three external and one
internal low-profile PCIe
Gen-3 slots. They contain:
■ PCIe slot 2: NVMe
Switch PCIe Card
■ PCIe slot 3: Dual 10
GbE SFP+ PCIe 2.0 Low
Profile Adapter
■ PCIe slot 4: Dual-port
Internal 12Gb/s SAS3
host bus adapter
Three external and one
internal low-profile PCIe
Gen-3 slots. They contain:
■ PCIe slot 2: NVMe
Switch PCIe Card
■ PCIe slot 3: Dual 10
GbE SFP+ PCIe 2.0 Low
Profile Adapter
■ PCIe slot 4: Dual-port
Internal 12Gb/s SAS3
host bus adapter
Six external internal low-
profile PCIe Gen-3 slots.
They contain:
■ PCIe slot 1: Dual 10
GbE SFP+ PCIe 2.0 Low
Profile Adapter
■ PCIe slots 2, 5, 6: NVMe
Switch PCIe Card
■ PCIe slot 3: Dual-port
Internal 12Gb/s SAS3
host bus adapter
Three external and one
internal low-profile PCIe
Gen-3 slots for each server
node. They contain:
■ PCIe slot 1: Dual Port
QDR InfiniBand M3
PCIe 3.0 Low Profile
Adapter
--or--
PCIe slot 1: Dual 10
GbE SFP+ PCIe 2.0 Low
Profile Adapter
■ PCIe slot 2: Dual-port
External 12Gb/s SAS3
host bus adapter
■ PCIe slot 3: Dual-port
External 12Gb/s SAS3
host bus adapter
■ PCIe slot 4: Dual-port
Internal 12Gb/s SAS3
host bus adapter
Cluster
device
N/A N/A N/A One integrated cluster
device with node-to-node
interconnection is provided
