Oracle Database Appliance X3-2/X4-2 Front and Back Panels
Chapter2 • Overview of Oracle Database Appliance 41
Callout Description
1 Storage shelf OK/power indicator
2 Storage shelf fault indicator
3 Storage shelf Locate indicator
4 Drive fault indicator
5 Drive power/activity indicator
Oracle Database Appliance X3-2/X4-2 Back Panel
This section describes the back panel features for Oracle Database Appliance X3-2/X4-2. The
following figure shows the Oracle Database Appliance X4-2. The Oracle Database Appliance
X3-2 and Oracle Database Appliance X4-2 are identical except for the network card in PCIe
slot 1 (see “Server Node Back Panel Features” on page 42).
