Oracle Database Appliance X3-2/X4-2 Front and Back Panels
38 Oracle Database Appliance Owner's Guide • March 2017
Callout Description
5 Service ports (reserved for Oracle Service only)
6 SAS I/O module 1
7 Power Supply with Fan Module 2
8 SAS I/O module 0
Power Supply with Fan Module 1
9 Power Supply with Fan Module 1
Oracle Database Appliance X3-2/X4-2 Front and Back
Panels
This section describes Oracle Database ApplianceX3-2/X4-2 front and back panels. If you have
Oracle Database Appliance X6-2 series, see “Oracle Database Appliance X6-2S/X6-2M/X6-2L
Front and Back Panels” on page 19. If you have Oracle Database Appliance X6-2-HA,
see “Oracle Database Appliance X6-2-HA Front and Back Panels” on page 23. If you
have Oracle Database Appliance X5-2, see “Oracle Database Appliance X5-2 Front and
Back Panels” on page 31. If you have Oracle Database Appliance Version 1, see “Oracle
Database Appliance Version 1 Front and Back Panels” on page 45.
■
“Oracle Database Appliance X3-2/X4-2 Front Panel” on page 38
■
“Oracle Database Appliance X3-2/X4-2 Back Panel” on page 41
Oracle Database Appliance X3-2/X4-2 Front Panel
Oracle Database Appliance X3-2/X4-2 includes two server nodes (either two Sun Server X3-
2's, or two Sun Server X4-2's) and an Oracle DE2-24P storage shelf. The entire unit occupies
4RU. The optional DE2-24P storage expansion shelf requires an additional 2RU, increasing the
total to 6RU.
The following figure shows the front of Oracle Database Appliance X3-2 with an optional
storage expansion shelf. Except for product labeling, Oracle Database Appliance X4-2 is
identical in appearance.
