Oracle Database Appliance X5-2 Front and Back Panels
Chapter2 • Overview of Oracle Database Appliance 37
Storage Shelf Back Panel Features
The following figure shows the Oracle Database Appliance X5-2 storage shelf back panel
features.
Caution - The network ports on the storage shelf are intended for use by service engineers only.
Callout Description
1 AC power fail indicator
2 Power supply status indicator
3 Fan fail indicator
4 DC power fail indicator
