Oracle Database Appliance X6-2-HA Owner's Guide

Stabilize the Rack for Installation
Chapter4 • Installing the System Into a Rack 65
Note - The links in the following table take you to instructions outside of the Oracle Database
Appliance library to the Oracle Server X6-2 or Oracle Server X6-2L documentation libraries.
Use your browser's Back button to return to the Oracle Database Appliance library.
Oracle Database Appliance X6-2S/X6-2M Oracle Database Appliance X6-2L
Verify Rackmount Hardware Verify Rackmount Hardware
Install Mounting Brackets Install Mounting Brackets
Mark the Rackmount Location Mark the Rackmount Location
Connect AC Power Cables Before Installing Tool-less
Slide-Rails in Sun Rack II 1042
Connect AC Power Cables Before Installing Tool-less
Slide-Rails in Sun Rack II 1042
Attach the Tool-less Slide-Rail Assemblies Attach the Tool-less Slide-Rail Assemblies
Install the Server into the Slide-Rail Assemblies Install the Server into the Slide-Rail Assemblies
Install the Cable Management Arm and Verify Operation Install the Cable Management Arm and Verify Operation
Optional: Install the Shipping Bracket With Cable
Trough
Optional: Install the Shipping Bracket With Cable
Trough
Inserting Oracle Database Appliance X3-2/X4-2/
X5-2 and X6-2-HA Into a Rack
This section describes how to install the server nodes and storage shelves of Oracle Database
Appliance X3-2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle
Database Appliance X6-2-HA into a rack. If you are installing an Oracle Database Appliance
X6-2S/X6-2M/X6-2L, see “Inserting Oracle Database Appliance X6-2S/X6-2M/X6-2L Into a
Rack” on page 63. If you are installing Oracle Database Appliance Version 1, see “Inserting
Oracle Database Appliance Version 1 Into a Rack” on page 92.
This section includes the following subsections:
■
“Contents of the Shipping Pallet” on page 66
■
“Installation Sequence” on page 66
■
“Verify Component Compatibility” on page 66
■
“Tools and Equipment Needed” on page 67
■
“Stabilize the Rack for Installation” on page 67
■
“Applying Labels” on page 68
■
“Installing the Storage Shelves Into a Rack” on page 70
■
“Installing the Server Nodes Into a Rack” on page 91
Caution - Personal injury or equipment damage. Always install equipment in a rack from the
bottom up. See “Installation Sequence” on page 66.
