Oracle Database Appliance X6-2-HA Owner's Guide

Oracle Database Appliance X5-2 Front and Back Panels
Chapter2 • Overview of Oracle Database Appliance 31
Callout Description
3 Power supply status indicator
4 DC power fail indicator
5 Power Supply with Fan Module 0
6 Service ports (reserved for Oracle Service only)
7 SAS I/O module 1
8 SAS I/O module 0
9 Power Supply with Fan Module 1
Oracle Database Appliance X5-2 Front and Back Panels
This section describes Oracle Database Appliance X5-2 front and back panels. If you have
Oracle Database Appliance X6-2 series, see “Oracle Database Appliance X6-2S/X6-2M/X6-2L
Front and Back Panels” on page 19. If you have Oracle Database Appliance X6-2-HA,
see “Oracle Database Appliance X6-2-HA Front and Back Panels” on page 23. If you
have Oracle Database Appliance X3-2 or Oracle Database Appliance X4-2, see “Oracle
Database Appliance X3-2/X4-2 Front and Back Panels” on page 38. If you have Oracle
Database Appliance Version 1, see “Oracle Database Appliance Version 1 Front and Back
Panels” on page 45.
■
“Oracle Database Appliance X5-2 Front Panel” on page 31
■
“Oracle Database Appliance X5-2 Back Panel” on page 34
Oracle Database Appliance X5-2 Front Panel
Oracle Database Appliance X5-2 includes two server nodes (two Oracle Server X5-2's) and an
Oracle DE2-24C storage shelf. The entire unit occupies 6RU. The optional storage expansion
shelf requires an additional 4RU, increasing the total to 10RU.
The following figure shows the front of Oracle Database Appliance X5-2 with an optional
storage expansion shelf.
