Oracle Database Appliance X6-2-HA Owner's Guide

Oracle Database Appliance Version 1 Front and Back Panels
Chapter2 • Overview of Oracle Database Appliance 45
Callout Description
3 Fan fail indicator
4 DC power fail indicator
5 Power Supply with Fan Module 0
6 Service ports (reserved for Oracle Service only)
7 SAS I/O module 1
8 SAS I/O module 0
9 Power Supply with Fan Module 1
Oracle Database Appliance Version 1 Front and Back
Panels
This section describes Oracle Database Appliance Version 1 front and back panels. If you have
Oracle Database Appliance X6-2S/X6-2M/X6-2L, see “Oracle Database Appliance X6-2S/
X6-2M/X6-2L Front and Back Panels” on page 19. If you have Oracle Database Appliance
X6-2-HA, see “Oracle Database Appliance X6-2-HA Front and Back Panels” on page 23.
If you have Oracle Database Appliance X5-2, see “Oracle Database Appliance X5-2 Front
and Back Panels” on page 31. If you have Oracle Database Appliance X3-2 or Oracle
Database Appliance X4-2, see “Oracle Database Appliance X3-2/X4-2 Front and Back
Panels” on page 38.
■
“Oracle Database Appliance Version 1 Front Panel” on page 45
■
“Oracle Database Appliance Version 1 Back Panel” on page 47
Oracle Database Appliance Version 1 Front Panel
Oracle Database Appliance Version 1 includes two server nodes, SN0 and SN1. SN0 is on the
bottom and SN1 is on the top. Server nodes are also called system controllers.
The following figure shows Oracle Database Appliance Version 1 front panel and describes
its components.

Oracle Database Appliance X6-2-HA Specifications

General

Brand	Oracle
Model	Database Appliance X6-2-HA
Category	Storage
Language	English
