Oracle Database Appliance X3-2/X4-2 Front and Back Panels
44 Oracle Database Appliance Owner's Guide • March 2017
Callout Description Callout Description
private cluster interconnect between server
nodes.
7 PCIe card slot 2. Provides two SAS2
connectors used to connect the servers to the
storage shelf and the storage expansion shelf.
15 USB 2.0 connectors (2)
8 PCIe card slot 3. Provides two SAS2
connectors used to connect the servers to the
storage shelf and the storage expansion shelf.
16 DB-15 video connector
Storage Shelf Back Panel Features
The following figure shows the Oracle Database Appliance X3-2/X4-2 storage shelf back
panel features.
Caution - The network ports on the storage shelf are intended for use by service engineers only.
Callout Description
1 AC power fail indicator
2 Power supply status indicator
