Inserting Oracle Database Appliance Into a Rack
62 Oracle Database Appliance Owner's Guide • March 2017
Feature Oracle Database
Appliance Version 1
Oracle Database
Appliance X3-2/X4-2
Oracle Database
Appliance X5-2
Rack horizontal opening
and unit vertical pitch
Conforms to ANSI/EIA
310-D-1992 or IEC 60927
standards.
Conforms to ANSI/EIA
310-D-1992 or IEC 60927
standards.
Conforms to ANSI/EIA
310-D-1992 or IEC 60927
standards.
Distance between front and
rear mounting planes
Minimum 660.4 mm and
maximum 876.3 mm (26 in
to 34.5 in).
Minimum 610 mm and
maximum 915 mm (24 in
to 36 in).
Minimum 610 mm and
maximum 915 mm (24 in
to 36 in).
Clearance depth in front of
front mounting plane
Distance to front cabinet
door is at least 25.4 mm (1
in).
Distance to front cabinet
door is at least 25.4 mm (1
in).
Distance to front cabinet
door is at least 25.4 mm (1
in).
Clearance depth behind
front mounting plane
Distance to rear cabinet
door is at least 700 mm
(27.5 in).
Distance to rear cabinet
door is at least 900 mm
(35.43 in) with the cable
management arm, or 800
mm (31.5 in) without the
cable management arm.
Distance to rear cabinet
door is at least 900 mm
(35.43 in) with the cable
management arm, or 800
mm (31.5 in) without the
cable management arm.
Clearance width between
front and rear mounting
planes
Distance between
structural supports and
cable troughs is at least
456 mm (18 in).
Distance between
structural supports and
cable troughs is at least
456 mm (18 in).
Distance between
structural supports and
cable troughs is at least
456 mm (18 in).
Minimum clearance for
service access
Front clearance: 123.2 cm
(48.5 in)
Rear clearance: 91 cm (36
in)
Front clearance: 123.2 cm
(48.5 in)
Rear clearance: 91 cm (36
in)
Front clearance: 123.2 cm
(48.5 in)
Rear clearance: 91 cm (36
in)
Server node dimensions “Physical Specifications
for Oracle Database
Appliance Version 1 and
Models X3-2, X4-2 and
X5-2” on page 49
“Physical Specifications
for Oracle Database
Appliance Version 1 and
Models X3-2, X4-2 and
X5-2” on page 49
“Physical Specifications
for Oracle Database
Appliance Version 1 and
Models X3-2, X4-2 and
X5-2” on page 49
Storage shelf dimensions N/A “Physical Specifications
for Oracle Database
Appliance Version 1 and
Models X3-2, X4-2 and
X5-2” on page 49
“Physical Specifications
for Oracle Database
Appliance Version 1 and
Models X3-2, X4-2 and
X5-2” on page 49
Caution - Personal injury or equipment damage. Always load equipment into a rack from the
bottom up so that it will not become top-heavy and tip over. Deploy your rack’s anti-tilt bar to
prevent the rack from tilting during equipment installation. This caution is not applicable if an
earthquake kit has been installed on the rack and it is bolted to the floor.
Inserting Oracle Database Appliance Into a Rack
This section describes how to install an Oracle Database Appliance into a rack as follows:
■
“Inserting Oracle Database Appliance X6-2S/X6-2M/X6-2L Into a Rack” on page 63
