Oracle Database Appliance X6-2-HA Owner's Guide

Rack Compatibility Requirements
Chapter4 • Installing the System Into a Rack 61
Feature Oracle Database
Appliance X6-2S/X6-2M
Oracle Database
Appliance X6-2L
Oracle Database
Appliance X6-2-HA
10RU with optional
storage expansion shelf.
Rack horizontal opening
and unit vertical pitch
Conforms to ANSI/EIA
310-D-1992 or IEC 60927
standards.
Conforms to ANSI/EIA
310-D-1992 or IEC 60927
standards.
Conforms to ANSI/EIA
310-D-1992 or IEC 60927
standards.
Distance between front and
rear mounting planes
Minimum 610 mm and
maximum 915 mm (24 in
to 36 in).
Minimum 610 mm and
maximum 915 mm (24 in
to 36 in).
Minimum 610 mm and
maximum 915 mm (24 in
to 36 in).
Clearance depth in front of
front mounting plane
Distance to front cabinet
door is at least 25.4 mm (1
in).
Distance to front cabinet
door is at least 25.4 mm (1
in).
Distance to front cabinet
door is at least 25.4 mm (1
in).
Clearance depth behind
front mounting plane
Distance to rear cabinet
door is at least 900 mm
(35.43 in) with the cable
management arm, or 800
mm (31.5 in) without the
cable management arm.
Distance to rear cabinet
door is at least 900 mm
(35.43 in) with the cable
management arm, or 800
mm (31.5 in) without the
cable management arm.
Distance to rear cabinet
door is at least 900 mm
(35.43 in) with the cable
management arm, or 800
mm (31.5 in) without the
cable management arm.
Clearance width between
front and rear mounting
planes
Distance between
structural supports and
cable troughs is at least
456 mm (18 in).
Distance between
structural supports and
cable troughs is at least
456 mm (18 in).
Distance between
structural supports and
cable troughs is at least
456 mm (18 in).
Minimum clearance for
service access
Front clearance: 123.2 cm
(48.5 in)
Rear clearance: 91 cm (36
in)
Front clearance: 123.2 cm
(48.5 in)
Rear clearance: 91 cm (36
in)
Front clearance: 123.2 cm
(48.5 in)
Rear clearance: 91 cm (36
in)
Server node dimensions “Physical Specifications
for Oracle Database
Appliance X6-2
Series” on page 49
“Physical Specifications
for Oracle Database
Appliance X6-2
Series” on page 49
“Physical Specifications
for Oracle Database
Appliance X6-2
Series” on page 49
Storage shelf dimensions N/A N/A “Physical Specifications
for Oracle Database
Appliance X6-2
Series” on page 49
For Oracle Database Appliance Version 1 and Oracle Database Appliance X3-2/X4-2/X5-2:
Feature Oracle Database
Appliance Version 1
Oracle Database
Appliance X3-2/X4-2
Oracle Database
Appliance X5-2
Rack structure Four-post rack (mounting
at both front and rear).
Two-post racks are not
compatible.
Four-post rack (mounting
at both front and rear).
Two-post racks are not
compatible.
Four-post rack (mounting
at both front and rear).
Two-post racks are not
compatible.
Space available Must have 4RU (rack
units) of space available.
4RU without optional
storage expansion shelf.
6RU with optional storage
expansion shelf.
6RU without optional
storage expansion shelf.
10RU with optional
storage expansion shelf.
