Oracle Database Appliance X6-2-HA Owner's Guide

Oracle Database Appliance Specifications
Chapter2 • Overview of Oracle Database Appliance 49
Physical Specifications for Oracle Database Appliance X6-2
Series
Item Oracle Database
Appliance X6-2S
Oracle Database
Appliance X6-2M
Oracle Database
Appliance X6-2L
Oracle Database
Appliance X6-2-HA
Height 42.6 mm (1.7 in) 42.6 mm (1.7 in) 87.6 mm (3.5 in) 42.6 mm (1.7 in) per
server node
175 mm (6.9 in) per
storage shelf
Width 436.5 mm (17.2 in) 436.5 mm (17.2 in) 445.0 mm (17.5 in) 436.5 mm (17.2 in) per
server node
Storage shelf: 446.0
mm (17.6 in)
Depth 737.0 mm (29.0 in) 737.0 mm (29.0 in) 737.0 mm (29.0 in) 737.0 mm (29.0 in) per
server node
Storage shelf: 558.0
mm (22.0 in)
Weight 16.1 kg (35.4 lbs) 16.1 kg (35.4 lbs) 29.0 kg (64.0 lbs) 16.1 kg (34.5 lbs) per
server node
38.0 kg (84.0 lbs) per
storage shelf
Physical Specifications for Oracle Database Appliance
Version 1 and Models X3-2, X4-2 and X5-2
Item Oracle Database Appliance
Version 1
Oracle Database Appliance X3-
2/X4-2
Oracle Database Appliance X5-2
Height 175.1 mm (6.9 in) 42.6 mm (1.7 in) per server node
87.9 mm (3.5 in) per storage
shelf
42.6 mm (1.7 in) per server node
175 mm (6.9 in) per storage shelf
Width 437.0 mm (17.2 in) (without
mounting ears)
482.6 mm (19 in) (with mounting
ears)
Server node: 436.5 mm (17.2 in)
Storage shelf: 483.0 mm (19.0
in)
Server node: 436.5 mm (17.2 in)
Storage shelf: 483.0 mm (19.0
in)
Depth 762.0 mm (30.0 in)
782.0 mm (30.8 in) (including
fan module handles and latches)
Server node: 737.0 mm (29.0 in)
Storage shelf: 630.0 mm (24.8
in)
Server node: 737.0 mm (29.0 in)
Storage shelf: 630.0 mm (24.8
in)
Weight 72.6 kg (160.0 lbs) 16.3 kg (36.0 lbs) per server
node
24.0 kg (52.9 lbs) per storage
shelf
16.3 kg (36.0 lbs) per server
node
37.2 kg (82.0 lbs) per storage
shelf
