Rear Panel Components
No. Description
13 Drive 3 (or NVMe drive 1)
14 Drive 2 (or NVMe drive 0)
15 Drive 4 (or NVMe drive 2)
16 Drive 5 (or NVMe drive 3)
17 Drive 6
18 Drive 7
Related Information
■
“Server Overview” on page 10
■
“Rear Panel Components” on page 13
■
“Connect Cables” on page 51
Rear Panel Components
Note - You must follow the proper sequence when connecting cables to the server. Do not
connect the power cords until all data cables have been connected.
Understanding the Server 13
