Install the Server Into the Slide Rail Assemblies
11.
Install the server into the slide rail assemblies.
See “Install the Server Into the Slide Rail Assemblies” on page 35.
Related Information
■
“Rack Compatibility” on page 26
■
“Install the Rackmount Hardware” on page 29
■
“Install the Server Into the Slide Rail Assemblies” on page 35
Install the Server Into the Slide Rail Assemblies
Use this procedure to install the server chassis, with mounting brackets attached, into the slide
rail assemblies that are mounted to the rack.
Caution - This procedure requires a minimum of two people because of the weight of the
server. Attempting this procedure alone could result in equipment damage or personal injury.
Caution - Always load equipment into a rack from the bottom up so that the rack does not
become top-heavy and tip over. Extend the rack's antitilt bar to prevent the rack from tipping
during equipment installation.
1.
Attach the rackmount hardware to the server and the rack.
See “Install the Rackmount Hardware” on page 29 and “Attach Slide Rail Assemblies to the
Rack” on page 31.
2.
Push the slide rails into the slide rail assemblies in the rack as far as possible.
3.
Position the server so that the rear ends of the mounting brackets are aligned
with the slide rail assemblies that are mounted in the rack.
Installing the Server 35
