Install the Rackmount Hardware
Related Information
■
Rack documentation
■
SPARC T8-1 Server Safety and Compliance Guide
■
“Rack Compatibility” on page 26
■
“Rack Cautions” on page 27
Install the Rackmount Hardware
Complete the following task to remove the mounting brackets from the slide rail assemblies
before installation.
1.
Unpack the slide rails.
The rackmount kit contains two slide rails, two mounting brackets, and optional securing
screws.
Note - Refer to the rackmount kit installation card for simplified instructions about installing
your server into a 4-post rack, using the slide rail and CMA options.
No. Description
1 Slide rails
2 Mounting brackets
3 Four M4 x 5 fine-pitch mounting bracket securing screws (not used)
Installing the Server 29
