Install the Rackmount Hardware
No. Description
4 Installation card
2.
Position a mounting bracket against the chassis so that the slide rail lock is
at the server front, and the five keyhole openings on the mounting bracket are
aligned with the five locating pins on the side of the chassis.
No. Description
1 Server front
2 Slide rail lock
3 Mounting bracket
4 Mounting bracket clip
3.
With the heads of the five chassis locating pins protruding through the five
keyhole openings in the mounting bracket, pull the mounting bracket toward
30 SPARC T8-1 Server Installation Guide • June 2019
