Rack Compatibility
not ordered with the server are shipped separately. If possible, install these components prior to
installing the server in a rack.
Except for the rackmount kits, if you ordered any options that are not factory-installed, refer
to the service manual for the server and the component's documentation for installation
instructions.
Note - The list of optional components can be updated without notice. Refer to the product web
pages for the most current list of components supported in the server.
Related Information
■
Optional component documentation
■
SPARC T8-1 Server Service Manual
Rack Compatibility
Check that your rack is compatible with the slide rail and CMA options. The optional slide rails
are compatible with a wide range of equipment racks that meet the following standards.
Item Requirement
Structure 4-post rack (mounting at both front and rear). 2-post racks are not
compatible.
Rack horizontal opening and unit vertical pitch Conforms to ANSI/EIA 310-D-1992 or IEC 60927 standards.
Rack rail mounting hole sizes Only 9.5-mm square hole and M6 round mounting holes are
supported. All other sizes, including 7.2-mm, M5, or 10-32
mounting holes, are not supported.
Distance between front and rear mounting
planes
Minimum: 24.5 in. (622 mm).
Maximum: 35.25 in. (895 mm).
Clearance depth in front of front mounting
plane
Distance to front cabinet door is at least 1.06 in. (27 mm).
Clearance depth behind front mounting plane Distance to rear cabinet door is at least 35.5 in. (900 mm) with the
CMA, or 30.4 in. (770 mm) without the CMA.
Clearance width between front and rear
mounting planes
Distance between structural supports and cable troughs is at least
18 in. (456 mm).
Server dimensions Depth: 29.0 in. (737 mm).
Width: 17.5 in. (445 mm).
26 SPARC T8-1 Server Installation Guide • June 2019
