Install the Server Into the Slide Rail Assemblies
4.
Insert the mounting brackets into the slide rails, and then push the server
into the rack until the mounting brackets encounter the slide rail stops
(approximately 12 inches, or 30 cm).
No. Description
1 Inserting mounting bracket into slide rail
2 Slide rail release lever
5.
Simultaneously pull down and hold the slide rail release levers on each
mounting bracket while you push the server into the rack.
Continue pushing the server into the rack until the slide rail locks (on the front of the mounting
brackets) engage the slide rail assemblies.
36 SPARC T8-1 Server Installation Guide • June 2019
