Install the Server Into the Slide Rail Assemblies
You hear an audible click when the slide rail locks are engaged.
Caution - Verify that the server is securely mounted in the rack and that the slide rail locks are
engaged with the mounting brackets before you install the optional CMA.
6.
(Optional) If you chose to secure the slide rail assembly to the rack with screws,
insert the M4 mounting screws that are provided with the rail kit, through the
front left and right slide rail brackets and rack posts.
7.
(Optional.) Attach the CMA.
See “Prepare the CMA for Installation” on page 38.
If you are not using the CMA, see “Verify Operation of Slide Rails and CMA” on page 47.
Related Information
■
“Prepare the CMA for Installation” on page 38
■
“Attach the CMA to the Server” on page 41
■
“Verify Operation of Slide Rails and CMA” on page 47
Installing the Server 37
