a. Grasp connector. Support the connector by grasping the positive end of the
connector.
Caution:
The connector must be supported, otherwise damage to the soldered
contacts could occur.
b. Slide battery under lips at positive end of connector. While supporting the
connector, hold the battery at an angle with the positive side facing up, and slide
the battery under the lips at the positive end of the connector.
Note:
Positive side of battery is marked with a "+".
c. Fully seat battery onto housing floor. Gently push the battery onto the floor of the
housing until the battery is fully seated. There should be an audible "snap".
Note:
Insert the battery so that the positive (+) side is facing up.
Chapter 4
Replacing the Battery
4-15
