Hardware Overviews
FIGURE 11
Sun Disk Shelf Rear Panel
Figure Legend
1 Power supply modules with built-in fans. Power supply
0 is on the left and power supply 1 is on the right.
2 Removable SAS Interface Module (SIM) Boards. SIM
0 is on the left, and SIM 1 is on the right.
I/O Module Indicators
The following disk shelves have I/O Modules (IOMs):
Oracle Storage Drive Enclosure DE2-24P
Oracle Storage Drive Enclosure DE2-24C
FIGURE 12
DE2 Drive Enclosure I/O Module Indicators
Installation Prerequisites and Hardware Overviews 27
