Hardware Overviews
Figure Legend
4 Power button 5 Service Processor OK LED (green) 6 Fan/CPU/Memory Service
Required LED
7 USB 2.0 ports
Note - The LEDs below the Fan/CPU/Memory Service Required LED are not currently used.
ZS3-2 Rear Panel Components
The ZS3-2 controller PCIe slots and rear panel components are shown in the following figure.
For more information about PCIe cards, see “ZS3-2 PCIe Options” in Oracle ZFS Storage
Appliance Customer Service Manual.
FIGURE 23
ZS3-2 Controller Rear Panel
Figure Legend
1 SAS-2 HBA (slot 1) 2 4x4 SAS-2 HBA (slot 2) 3 PCIe slot 3
4 PCIe slot 4 5 PCIe slot 5 6 PCIe slot 6
7 AC power supplies PS1 (top), PS0
(bottom)
8 System status LEDs 9 USB 2.0 ports
Installation Prerequisites and Hardware Overviews 41
