Load Board (Online Only)
The completed example of the product can now be loaded into the system to
capture a Background Image.
• Click Load Board
Take care when loading a board manually into the system
Once the board is loaded into the adaptor a Background Image can be
acquired.
• Click Acquire Background Image
The entire area defined by the Board Size is photographed and
presented as a single image in the Graphic Editor
Once complete proceed to the next step by clicking
