TBA Compatible Inspections
The following inspections are compatible with the TBA Setup Tool.
Solder Volume, checks for sufficient solder
Solder Open, checks for open solder joints / lifted leads
Short, checks for bridges between terminals or components
A suitable TBA inspector must also be available, more
information on Inspections and Inspectors can be found in
Inspection Config
Setting up a TBA Inspection
To set up a TBA Inspection using the Setup Tool;
• Select the component
A board is required in the machine for these steps.
• Acquire an image of the component
• From the Recipe Table View right click the Inspection to be set-up
The Recipe Editor views can be switched by clicking in the
top right of the Editor.
•
From the context menu select configure
If no context menu is available this indicates that a suitable
Inspector is not available. You can check the Inspection Config
The TBA Setup Tool will open, for each Tab in turn;
• Check the displayed result
• Adjust parameters to achieve the desired result on the sample
• Click to check the settings against the Image Library
• Check the Performance Summary to see that the results are good
• Choose to Update the Recipe, or both the Recipe and Library
If you do not wish to update, close the Tool with or Cancel
