• Polarity Mark, reports an error when the component is detected as
being incorrectly oriented.
Inspection is on or off, criteria for inspection are defined by the Polarity
Mark tab of the Property Editor.
• Pin Presence, reports an error when the end terminals of the
component are not detected.
Inspection is on or off, no other setup is required.
An Inspection which is switched on is indicated by . To turn off
an Inspection click the checkbox, the off state is indicated by .
