Hardware
Technical Data
OPEN-XS MLIII OPEN-XS EtherCAT
Part Number 2SMPM6396/0C 2SMPM5990/0C
CPU Intel®Atom 1.6GHz
Storage Compact Flash 1 GB / 4GB / SSD 128GB
RAM 2 GB
Monitor port VGA
Ethernet 1 x 100/1000 Mbps
USB 3 x 2.0
Serial Line 2 x RS232 – 1 x RS232/422/485
Fast Input 4
Fast Output 3
Emergency Stop 1
Operating System Single OS (Windows CE 6.0) / Dual OS (Windows CE 6.0 + WES7 32 bit)
Retentive memory 256Kb
Other features System timers and watch dog
Power Supply 24 VDC
Controlled axes Up to 8
Number of Processes Up to 2
Primary Fieldbus Mechatrolink III EtherCAT(SoE and CoE proles)
Secondary Fieldbus
EtherCAT(SoE and CoE proles)
CANopen
CANopen
Operating Temperature 0°... +50°C
Relative Humidity 90% no condensation
4 Analog Axes slave module A-432 dimensions, front and side view
32
