OSRAM BT Control | General information
12
Function validation
To validate the assembly, the construction must be checked and the connection stability and connection distance tested.
The check should be done using:
— The OSRAM BT app and a mobile device for testing the range of the mobile device to the BT antenna
— In case of Swarm function: A second BT Control device to test the point-to-point range between Swarm participants
Please note:
The result of the validation is not an index of replicability in all environments and application situations.
2 cm
4 cm
> 5 cm
Metal
Metal
> 5 cm
Metal-free zone
for antenna area!
3 cm
2 cm
> 4 cm
Pole integration
Pole:
Top view
2 cm
4 cm
> 4 cm
> 5 cm
Metal
Metal-free zone
for antenna area!
Transition area:
Corner mounting
