OSRAM BT Control | General information
7
2.3.1 OSRAM DALI sensors and couplers G2 – DALI-2-certified
The following components can be combined with all three BT Control devices (all dimensions in m):
2.5
3.3
5.3
Mounting height 2 2.5 3 4 5
Presence 2.5 3.3 4 5 –
Motion 4.5 5.3 6 7 7
Mounting height 2 2.5 3 4 5
Presence 2.5 3.3 4 5 –
Motion 4.5 5.3 6 7 7
Name EAN
DALI SENSOR LS/PD LI G2 4062172072069
Name EAN
DALI COUPLER E G2 4062172072212
ECO CI KIT (optional) 4008321392091
Mounting height 2 2.5 3 4 5
Presence 2.5 3.3 4 5 –
Motion 4.5 5.3 6 7 7
Name EAN
DALI SENSOR LS/PD LI G2 4062172072069
LS/PD AP KIT 4052899173385
Mounting height 4 6 8 10
Presence – – – –
Motion 6.7 10 13.4 –
Vehicles 6.7 10 13.4 16
Name EAN
DALI COUPLER HF G2 4062172072199
HF LS LI Sensor 4052899921481
ECO CI KIT (optional) 4008321392091
Mounting height 2 2.5 3 4 5
Presence 2.5 3.3 4 5 –
Motion 4.5 5.3 6 7 7
Name EAN
DALI COUPLER MULTI 3 G2 4062172072113
LS/PD MULTI 3 CI 4008321916648
ECO CI KIT (optional) 4008321392091
Mounting height 2 2.5 3 4 4.5
Presence – – – – –
Motion 12.5 15.5 19 21 21
Name EAN
DALI COUPLER LS HIGHBAY G2 4062172072137
VISION SENSOR 4008321957047
Mounting height 2 2.5 3 4
Presence 3 3.7 4.4 –
Motion 4 5 6 6.5
Name EAN
DALI SENSOR LS/PD UF G2 4062172072045
Name EAN
DALI SENSOR LS/PD CI G2 4062172072083
Name EAN
DALI COUPLER LS HIGHBAY G2 4062172072137
HIGH BAY SENSOR 4008321410078
12.0
10.0
Mounting height 4 6 8 10 13
Presence – – – – –
Motion 10 12 12 12 –
Vehicles 10 12 12 12 18
Range of third-party sensor
Name EAN
DALI COUPLER PUSHB G2 4062172087575
2.5
12.5
2.5
5.0
5.0
3.7
3
.
7
H
B
A
2.5
3.3
5.3
2.5
3.3
5.3
2.5
3.3
5.3
Max. 8 m
ca. 80°
ca. 35°
