OSRAM BT Control | General information
8
2.3.2 OSRAM DALI pushbutton coupler G2 – function modes
The following pre-programmed function modes 1-6 can be activated while using OSRAM BT Control devices together
with the DALI pushbutton coupler G2:
Name Function of input A Function of input B Function of input C Function of input D
1: 1-channel Tunable White
(default)
SP
*
: Switch on/off
LP
**
: Dim up/down
Groups: All (1–4)
SP: Toggle scene
LP: Change color temp.
Groups: All (1–4)
SP: Recall scene 1
LP: ---
Groups: All (1–4)
SP: Recall scene 2
LP: ---
Groups: All (1–4)
2: 2-channel Tunable White SP: Switch on/off
LP: Dim up/down
Group: 1
SP: Switch on/off
LP: Dim up/down
Group: 2
SP: ---
LP: Change color temp.
Group: 1
SP: ---
LP: Change color temp.
Group: 2
3: 2-channel dimming SP: Switch on/off
LP: Dim up/down
Group: 1
SP: Switch on/off
LP: Dim up/down
Group: 2
SP: On
LP: ---
Groups: All (1–4)
SP: Off
LP: ---
Groups: All (1–4)
4: 4-channel dimming SP: Switch on/off
LP: Dim up/down
Group: 1
SP: Switch on/off
LP: Dim up/down
Group: 2
SP: Switch on/off
LP: Dim up/down
Group: 3
SP: Switch on/off
LP: Dim up/down
Group: 4
5: Scene control SP: Recall scene 1
LP: ---
Groups: All (1–4)
SP: Recall scene 2
LP: ---
Groups: All (1–4)
SP: Recall scene 3
LP: ---
Groups: All (1–4)
SP: Recall scene 4
LP: ---
Groups: All (1–4)
6: 1-group Tunable White and
HCL
1)
SP: Switch on/off
LP: Dim up/down
Groups: All (1–4)
SP: ---
LP: Change color temp.
Groups: All (1–4)
SP: Recall scene 1
LP: ---
Groups: All (1–4)
SP: HCL resume
LP: ---
Groups: All (1–4)
Number of
OSRAM DALI sensors
Number of
OSRAM DALI PB couplers
Max. number of
OSRAM DALI ECGs
(at 25 °C ambient temperature)
Max. number of
OSRAM DALI ECGs
(at 60 °C ambient temperature)
1
0 32 32
1 32 32
2 32 32
3 32 32
4 32 32
2
0 32 32
1 32 32
2 32 32
3 32 32
4 32 32
3
0 32 32
1 32 32
2 32 32
3 32 30
4 28 26
4
0 32 30
1 30 28
2 28 26
3 26 24
4 24 22
2.3.3 Limitations on connectable devices
Relevant for all three OSRAM BT Control devices:
DALI ACU BT, DALI ECO BT and DALI ECO BT RTC (with integrated real-time clock)
1)
HCL only applicable with DALI ECO BT RTC Control device
*
SP = Short press
**
LP = Long press
