OSRAM BT Control | General information
4
Control features
Plug-&-play, out-of-the-box features Yes Yes Yes
Control and configuration via app (Android/iOS) Yes Yes Yes
Support of OSRAM DALI and DALI-2 sensors and couplers Yes Yes Yes
No. of different connectable pushbuttons 1 1 2
1)
DALI grouping Yes (up to 4) Yes (up to 4) Yes (up to 4)
Swarm function (wireless interconnection between controllers) Yes Yes Yes
Mounting type Flush box Luminaire integration
2)
Luminaire integration
2)
HCL function (automatic daytime-based color temperature
change)
- - Yes
Timer functions - - 4
2 General information
OSRAM BT Control devices are DALI lighting controls with a Bluetooth Low Energy (BLE) interface. All OSRAM BT Control
devices are powerful stand-alone units which can be configured and controlled with a smart device.
2.1 BT Control devices
Three hardware types of OSRAM BT Control devices are available:
— DALI ACU BT
— DALI ECO BT
— DALI ECO BT RTC (with integrated real-time clock)
Electrical parameters Value
V
AC
220-240 V; 50/60 Hz
P 0.3-3 W
t
a
-20 … + 60 °C
IP rating IP20
Max. DALI load 32 ECGs + 4 OSRAM DALI sensors or DALI pushbutton couplers
96 mA
DALI ACU BT DALI ECO BT DALI ECO BT RTC
All three hardware types of OSRAM BT Control devices feature the same electrical parameters:
1) Second pushbutton needs a resistor in the daisy chain
2) False ceiling integration with cable clamp (ECO CI Kit) possible
