1 Current list box Display current DTC errors.
#: Index
Description: DTC Description
Failure Type: Failure Type name
P Code: P Code
2 History list box Display historic DTC errors.
#: Index
Description: DTC description.
Failure Type: Failure Type name
P Code : P Code
3 [Toolbar] Save button Save a screen data as csv format le.
4 [Toolbar] Print button Print a screen data.
5 [Toolbar] History Clear Clear historic DTC errors.
When you clicked the button, the Message 14 will
beshown.
If you select ‘Yes’button, historic errors are cleared. But i
f the application failed to clear historic errors, the Message
15 will beshown.
6 When this screen is displayed When the ECU is not connected, the ECU connection will
be started. If failed to connect to the ECU, theMessage 7 will
be shown.
