Outback MATE User Manual

106
STATUS/FX/METERS--P00
charger 0.0 aac
current
DOWN UP TOP PORT
STATUS/FX/METERS--P00
input 0.0 aac
current
DOWN UP TOP PORT
STATUS/FX/METERS--P00
sell 0.0 aac
current
DOWN UP TOP PORT
STATUS/FX/METERS-P00
FX rmwarerevision
DOWN UP TOP PORT
STATUS/FX/METERS—---
end of meter menu
UP TOP STATUS
BATTERY SCREENS
STATUS/FX/METERS--P00
inverter 0.0 aac
current
DOWN UP TOP PORT
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/FX/BATT-----P00
battery 25.0 vdc
actual
DOWN STATUS PORT
STATUS/FX/BATT-----P00
battery 25.0 vdc
temp compensated
DOWN UP TOP PORT
STATUS/FX/BATT-----P00
absorb 28.8 vdc
set point
DOWN UP TOP PORT
STATUS/FX/BATT-----P00
absorb 01.5 hrs
time remaining
DOWN UP TOP PORT
STATUS/FX/BATT-----P00
oat 26.8 vdc
setpoint
DOWN UP TOP PORT
STATUS/FX/BATT------P00
oat 00.8 hrs
time remaining
DOWN UP TOP PORT
STATUS/FX/PAGE1-----
choose category:
MODES METER BATT PG2
STATUS/FX/BATT-------P00
reoat 25.0 vdc
setpoint
DOWN UP TOP PORT
STATUS/FX/BATT-------P00
equalize 28.8 vdc
setpoint
DOWN UP TOP PORT
STATUS/FX/BATT-----P00
batt temp. 255
(not in degree C/F)
DOWN UP TOP STATUS
STATUS/FX/BATT--—---
end of battery menu
UP TOP STATUS
ERRORS
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/FX/PAGE1-----
choose category:
MODES METER BATT PG2
STATUS/FX/BATT-----P00
equalize 02.0 hrs
time remaining
DOWN UP TOP PORT
STATUS/FX/PAGE2-----
choose category:
PG1 ERROR WARN PG3
STATUS/FX/ERROR—-P00
low ac output NO
voltage
DOWN STATUS PORT
STATUS/FX/ERROR—-P00
inverter NO
overtemp
DOWN UP TOP PORT
STATUS/FX/ERROR—-P00
low battery NO
voltage
DOWN UP TOP PORT
STATUS/FX/ERROR--P00
phase loss NO
error
DOWN UP TOP PORT
STATUS/FX/ERROR--P00
high battery NO
voltage
DOWN UP TOP PORT
STATUS/FX/ERROR—-P00
ac output NO
shorted
DOWN UP TOP PORT
STATUS/FX/ERROR—-P00
ac output NO
backfeed
DOWN UP TOP PORT
STATUS/FX/ERROR—-P00
stacking NO
error detected
DOWN UP TOP PORT
STATUS/FX/ERROR—----
end of error menu
UP TOP STATUS

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
