Outback MATE User Manual

107
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/FX/PAGE1-----
choose category:
MODES METER BATT PG2
STATUS/FX/PAGE2-----
choose category:
PG1 ERROR WARN PG3
STATUS/FX/WARN---P00
acin freq NO
too high
DOWN STATUS PORT
STATUS/FX/WARN---P00
acin freq NO
too low
DOWN UP TOP PORT
WARNINGS
STATUS/FX/WARN---P00
acin voltage NO
too high
DOWN UP TOP PORT
STATUS/FX/WARN---P00
acin voltage NO
too low
DOWN UP TOP PORT
STATUS/FX/WARN---P00
temperature NO
sensor fault
DOWN UP TOP PORT
STATUS/FX/WARN---P00
internal comm NO
error detected
DOWN UP TOP PORT
STATUS/FX/WARN---P00
internal fan NO
failure detected
DOWN UP PORT
STATUS/FX/WARN---P00
airtemp 204
DOWN UP PORT
STATUS/FX/WARN---P00
fettemp 204
DOWN UP PORT
STATUS/FX/WARN---P00
captemp 204
DOWN UP PORT
STATUS/FX/WARN---P00
ac input NO
current exceeds max
DOWN UP TOP PORT
STATUS/FX/WARN------
end of warnings
menu
UP TOP STATUS
DISCONNECT REASONS
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/FX/PAGE1-----
choose category:
MODES METER BATT PG2
STATUS/FX/PAGE2-----
choose category:
PG1 ERROR WARN PG3
STATUS/FX/PAGE3-----
choose category:
PG2 DISCON SELL MAIN
STATUS/FX/DISCON-P00
acin freq NO
too high
DOWN STATUS PORT
STATUS/FX/DISCON-P00
acin freq NO
too low
DOWN STATUS PORT
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS/FX/DISCON-P00
acin voltage NO
> max
DOWN UP TOP PORT
STATUS/FX/DISCON-P00
acin voltage NO
< min
DOWN UP TOP PORT
SELL
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/FX/PAGE1-----
choose category:
MODES METER BATT PG2
STATUS/FX/PAGE2-----
choose category:
PG1 ERROR WARN PG3
STATUS/FX/PAGE3-----
choose category:
PG2 DISCON SELL MAIN
STATUS/FX/DISCON----
end of DISCON menu
UP TOP STATUS
STATUS/FX/SELL---P00
stop sell 255
reason
STATUS PORT

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
