Outback MATE User Manual

108
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
STATUS/CC/MODE--P00
charger mode: Absorb
DOWN STATUS PORT
STATUS/CC/MODE--P00
aux relay:mode
Vent Fan
DOWN UP TOP PORT
STATUS/CC/MODE--P00
aux relay state: ON
DOWN UP TOP PORT
MODES
STATUS/CC/MODE--—---
end of mode menu
UP TOP STATUS
METERS
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
MODE: Absorb P01
in 11.2 vdc 0 adc
out 14.4 vdc 0 adc
DOWN STATUS PORT
STATUS/CC/METER--P00
charger 0 w
watts
DOWN UP TOP PORT
STATUS/CC/METER---P00
charger 0.0 kwh
kwhrs
DOWN UP TOP PORT
STATUS/CC/METER---P00
charger +000 adc
amps dc
DOWN UP TOP PORT
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS/CC/METER---P00
battery 14.4 vdc
voltage
DOWN UP TOP PORT
STATUS/CC/METER-—P00
panel 11 vdc
voltage
DOWN UP TOP PORT
STATUS/CC/METER-—---
end of meter menu
UP TOP STATUS
SET POINTS
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
STATUS/CC/SETP--—P00
Absorb 14.4 vdc
DOWN STATUS PORT
STATUS/CC/METER-P00
CC rmware revision
0001.008.000
DOWN UP TOP PORT
STATUS/CC/SETP--—P00
Float 13.6 vdc
DOWN UP TOP PORT
STATUS/CC/SETP--—---
end of setpoint
menu
UP TOP STATUS
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/CC/PAGE 1-------
MODE METER SETP PG2
STATUS/CC/LOGS1--P01
TODAY 0AH 00.0 kWH
11Vp 00.0Ap 0.00kWp
DOWN DAY- DAY+ PORT
STATUS/CC/LOG2---P01
TODAY battery
max 14.5V min 14.4V
DOWN DAY- DAY+ PORT
STATUS/CC/LOG3---P01
TODAY absorb oat
00:00 00:00
DOWN DAY- DAY+ PORT
STATUS/CC/LOG4------
end of logs display
TOP STATUS
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS/CC/PAGE 2-------
PG1 LOGS STAT MAIN
LOGS

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
