Outback MATE User Manual

115
ADV/CC/PAGE 1---------
choose category:
ADV CHGR CCADV PG2
ADV/CC/CHGR-----------
absorb voltage 14.4v
DOWN INC DEC PORT
ADV/CC/CHGR-----------
oat voltage 13.6v
DOWN INC DEC PORT
ADV/CC/CHGR-------P00
output current 78.08A
limit
DOWN INC DEC PORT
ADV/CC/CHGR----------
end charger menu
TOP ADV MAIN
ADV-----------------
choose device:
FX CC DC MATE
ADV/CC/PAGE 1---------
choose category:
ADV CHGR CCADV PG2
ADV/CC/ADVANCED-P01
snooze mode
<0.6 amp
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
wakeup mode
VOC change 1.5 V
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
wakeup mode
time 5 minutes
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
grid tie mode
nonGT
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
park MPP 77.0%
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
MPPT mode
auto track
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
Mpp range limit %VOC
minimum 1/2
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
absorb time
1/0 hours
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
absorb end amps
0 A
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
rebulk voltage
12.4 vdc
DOWN INC DEC PORT
ADV/CC/AVANCED-P01
vbatt calibration
14.4 vdc 0.0 v
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
RTS compensation
wide
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
RTS comp limit
lower limit 13.2 vdc
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
auto restart
mode 2
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
RTS comp limit
upper limit 14.1 vdc
DOWN INC DEC PORT
ADV/CC/ADVANCED-P01
reset CC to factory
defaults?
DOWN NO YES PORT
ADV/CC/ADVANCED-----
end CC advanced menu
TOP ADV MAIN
AGS SETUP
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV/MATE/PG1
choose category:
HBX GRIDUSE AGS PG2
ADV/MATE/AGS--------
Choose category:
QUIET VOLT
SETUP TIME START PG2
ADV-----------------
choose product:
FX CC DC MATE
ADV/MATE/AGS/SETUP--
ags port: 0
DOWN AGS INC DEC
ADV/MATE/AGS/SETUP--
AGS enabled: No
DOWN UP NO YES
ADV/MATE/AGS/SETUP---
AGS control: MAN-OFF
DOWN UP CHANGE
ADV/MATE/AGS/SETUP--
dc genset: No
DOWN UP NO YES
ADV/MATE/AGS/SETUP--
vdc genstop 38.0 vdc
DOWN UP INC DEC

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
