114
ADV/FX/AUX-------P00
aux output AC Drop
function
DOWN INC DEC PORT
STACKING
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
ADV/FX/PAGE2--------
choose category:
PG1 GRID GEN PG3
ADV/FX/PAGE3--------
choose category:
PG2 AUX STACK PG4
ADV-----------------
choose device:
FX CC MATE MATE
ADV/FX/STACK-------P00
stack 1-2PH Master
phase
DOWN INC DEC PORT
ADV/FX/STACK--------P00
stack Clasic Slave
phase
DOWN INC DEC PORT
ADV/FX/STACK-----P00
stack OB Slave L1
phase
DOWN INC DEC PORT
ADV/FX/STACK--------P00
stack OB Slave L2
phase
DOWN INC DEC PORT
ADV/FX/STACK---------P00
stack 3PH Master
phase
DOWN INC DEC PORT
ADV/FX/STACK---------P00
power save level 0
master adjust only
DOWN INC DEC PORT
ADV/FX/STACK---------P00
power save level 1
slave adjust only
DOWN INC DEC PORT
ADV/FX/STACK--------
stacking setup
completed
TOP ADV MAIN
ADV/FX/STACK---------P00
stack 3PH Slave
phase
DOWN INC DEC PORT
SELL
ADV/FX/PAGE3--------
choose category:
PG2 AUX STACK PG4
ADV/FX/PAGE4--------
choose category:
PG3 SELL CAL MAIN
ADV/FX/SELL----------P00
sell re 23.6 vdc
volts
DOWN INC DEC PORT
ADV/FX/SELL----------P00
grid tie IEEE
window
DOWN IEEE USER PORT
ADV/FX/SELL------P00
grid tie ---
authority
DOWN INC DEC PORT
ADV/FX/SELL---------P00
selling setup
Completed
TOP ADV MAIN
CALIBRATE
ADV/FX/PAGE4--------
choose category:
PG3 SELL CAL MAIN
ADV/FX/CALIBRATE-P00
vac input 120 vac
adjustment
DOWN INC DEC PORT
ADV/FX/CALIBRATE-P00
battery vdc 25.4 vdc
adjustment
DOWN INC DEC PORT
ADV/FX/CALIBRATE----
calibration setup
completed
TOP ADV MAIN
ADV/FX/CALIBRATE-P00
vac output 120 vac
adjustment
DOWN INC DEC PORT
AUX (CHARGE CONTROL-
LER FUNCTION)
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV-----------------
choose device:
FX CC DC MATE
