Outback MATE - Page 113

113
ADV/FX/GEN-----------P00
ac2/gen 140 vac
upper limit
DOWN INC DEC PORT
ADV/FX/GEN-----------P00
ac2/gen 60.0 aac
input limit
DOWN INC DEC PORT
ADV/FX/GEN-----------P00
ac2/gen 3 cycles
transfer delay
DOWN INC DEC PORT
ADV/FX/GEN-----------P00
ac2/gen OFF
support
DOWN OFF ON PORT
ADV/FX/GEN----------
GEN programming
completed
TOP ADV MAIN
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
AUX OUTPUT
ADV/FX/PAGE3--------
choose category:
PG2 AUX STACK PG4
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
ADV-----------------
choose device:
FX CC DC MATE
ADV/FX/PAGE2--------
choose category:
ADV GRID GEN PG3
ADV/FX/AUX-----------P00
aux output OFF
control
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
aux output ON
control
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
aux output Cool Fan
function
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
genalert 11.0 vdc
on setpoint
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
aux output AUTO
function
DOWN INC DEC PORT
ADV/FX/AUX----------P00
genalert 4 min
on delay
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
genalert 28.0 vdc
o set point
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
genalert 9 min
o delay
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
loadshed 22.0 vdc
o set point
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
ventfan 26.0 vdc
on set point
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
diversion 29.2 vdc
on set point
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
diversion 30 sec
o delay
DOWN INC DEC PORT
ADV/FX/AUX---------
Aux output
Setup completed
TOP ADV MAIN
ADV/FX/AUX-----------P00
ventfan o 5 min
period
DOWN INC DEC PORT
ADV/FX/AUX----------P00
aux output ON
control
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
aux output Cool Fan
function
DOWN INC DEC PORT
ADV/FX/AUX----------P00
aux output Vent Fan
function
DOWN INC DEC PORT
ADV/FX/AUX----------P00
aux output Fault
function
DOWN INC DEC PORT
ADV/FX/AUX----------P00
aux output GenAlert
function
DOWN INC DEC PORT
ADV/FX/AUX---------P00
aux output Remote
function
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
aux output DivertDC
function
DOWN INC DEC PORT
ADV/FX/AUX----------P00
aux output DivertAC
function
DOWN INC DEC PORT
ADV/FX/AUX-----------P00
aux output LoadShed
function
DOWN INC DEC PORT
PRESS 6 TIMES
